自動分配範圍：建立 Apigee 執行個體時，允許 Apigee 從分配給 Google 的較大範圍中，分配任何可用的不重疊範圍。每次重新建立執行個體時，系統都會自動分配 IP 範圍。在這種情況下，如果新的執行個體可以使用新的 IP 範圍，且該範圍與其他產品或服務不重疊，則新的執行個體可能會使用新的 IP 範圍。
指定 IP 範圍 - 您可以指定 Apigee 將使用的 IP 範圍。這個 IP 範圍必須來自與 Apigee 對等互連的非重疊範圍。如果您想為多個 Cloud 產品 (例如 Cloud SQL、Cloud Memorystore、Apigee 等) 分配較大的 IP 範圍，且希望能夠為每個產品指定實際 IP 範圍，這個選項就非常實用。只要範圍不是私用公開 IP 位址 (PUPI)，這個範圍可以是 RFC 1918 以外的 IP 範圍。
。
