앞서 설명한 사용 사례를 지원하는 것 외에도 확장 프로그램 프로세서는 다음과 같은 내장 Apigee 기능의 모든 이점을 제공합니다.
보안: 지능화된 API 보안은 API 트래픽을 지속적으로 모니터링하고 분석하여 의심스러운 API 요청을 식별하고 이러한 요청을 차단하거나 플래그를 지정하는 도구를 제공합니다.
수익 창출: Apigee 내에서 만든 맞춤 API 제품에 요금제를 추가하여 API가 사용될 때마다 수익을 창출합니다.
추적 가능성: Apigee의 분산 추적 시스템을 사용하면 여러 애플리케이션, 서비스, 데이터베이스, 프록시 간에 분산된 시스템에서 요청을 추적할 수 있습니다.
비즈니스 인텔리전스: Apigee API Analytics는 부하 분산기를 통해 흐르는 풍부한 정보를 수집하여 UI에서 데이터 시각화를 제공하거나 오프라인 분석을 위해 데이터를 다운로드하는 기능을 제공합니다.
Apigee 확장 프로그램 프로세서 작동 방식
Apigee 확장 프로그램 프로세서는 애플리케이션 부하 분산기의 데이터 처리 경로에서 Cloud Load Balancing을 사용하여 Apigee에 콜아웃을 보낼 수 있는 트래픽 확장 프로그램(서비스 확장 프로그램의 한 유형)입니다. 애플리케이션 부하 분산기와 서비스 확장 프로그램이 구성되면 다음 그림과 같이 애플리케이션 부하 분산기를 통과하는 트래픽이 서비스 확장 프로그램을 사용하여 Apigee 프록시 호출을 트리거합니다.
그림 1: Apigee 확장 프로그램 프로세서의 인프라와 Dataflow
이 다이어그램은 Apigee 확장 프로그램 프로세서 구성의 필수 구성요소를 간략히 보여줍니다.
모든 애플리케이션 백엔드를 포함하는 네트워크 엔드포인트 그룹(NEG)으로 구성된 백엔드 서비스가 있는 애플리케이션 부하 분산기
확장 프로그램 프로세서 전용 환경이 있고 apigee-service-extension-enabled 속성이 true로 설정된 Apigee 인스턴스
Private Service Connect (PSC) 엔드포인트를 사용하여 Apigee 런타임 평면에 연결하도록 구성된 트래픽 확장 프로그램(서비스 확장 프로그램의 한 유형)
확장 프로그램 프로세서를 사용하는 경우 환경, 환경 그룹, API 프록시에 추가 한도가 적용됩니다.
확장 프로그램 프로세서 구성에 사용되는 환경 그룹에는 최대 하나의 환경을 연결할 수 있습니다.
확장 프로그램 프로세서를 구성할 때 사용되는 환경에는 최대 50개의 API 프록시를 배포할 수 있습니다.
확장 프로그램 프로세서의 전용 환경에 배포된 API 프록시는 모두 동일한 프록시 유형이어야 합니다. API 프록시는 모두 표준 API 프록시이거나 모두 확장 가능 API 프록시여야 합니다.
표준 및 확장 가능 API 프록시는 확장 프로그램 프로세서 환경에서 혼합할 수 없습니다.
