GCPReady：表示 Google Cloud 已準備好所有必要資源。 Google Cloud 資源佈建程序期間發生的錯誤會反映在 GCPReady 條件的狀態中。
DPV2Ready：表示資料路徑程式設計的狀態，例如資料路徑已準備就緒並完成程式設計，可允許設定的持續性 IP 位址建立網路連線。
Ready：表示您的持續性 IP 位址設定有效且可正常運作。只要您已將應用程式設定為使用這些 IP 位址，就能透過這些位址連線至 Pod。如果前述三項條件也都是 True，這項條件就會設為 True。
回應模式
反應模式會決定系統在連結至持續性 IP 位址的 Pod 發生變更時的行為，例如跨節點移動，或是可使用新建立的相符 Pod 時。即使 Pod 發生變化，您也可以使用反應模式，確保持續可用的 IP 位址。
反應模式包括：
ReadyCondition
在「ReadyCondition」ReadyCondition模式中，持續性 IP 位址系統會優先考量 Pod 健康狀態。只有符合指定標籤且通過 Kubernetes 健康狀態探查的 Pod，才會獲得持續性 IP 位址，這表示 Pod 的 Ready 狀態為 True。如果應用程式必須確保接收持續性 IP 位址的 Pod 已完全準備好處理傳入和傳出流量，這個模式就是理想選擇。
存在
「Exists」模式會優先考量 Pod 的存在狀態。如果 Pod 符合設定中的標籤，且已排定在叢集中的特定節點上執行，則會附加持續性 IP 位址。這表示 Pod 存在，且有指定的執行位置。如果快速指派永久 IP 位址比嚴格的就緒狀態更重要，或是處於開發和測試等環境，即時連線可能比完整的應用程式健康狀態更重要，就非常適合使用這個模式。
StatefulSets
StatefulSets 是 Kubernetes 工作負載類型，專為需要穩定 ID 和永久儲存空間的應用程式設計。StatefulSet 中的 Pod 名稱可預測 (例如：my-app-0、my-app-1)。
部署作業
Deployment 是一種 Kubernetes 工作負載，用於管理無狀態應用程式，其中的 Pod 通常可互換。Deployment 中的 Pod 名稱無法完全預測。
用途
對於在 GKE 和 GKE Enterprise 上執行網路相關應用程式的網路和安全防護服務供應商，GKE Pod 的永久 IP 位址可解決多種用途。
GKE Pod 的永久 IP 位址可解決下列用途：
控管 NAT：將持續性 IP 位址指派給執行網路功能的 Pod，即可精細控管用於傳出流量的來源 IP 位址。方便您整合專屬的 NAT 邏輯。
專屬 IP 位址集區：專屬 IP 位址可讓您將特定位址與個別 5G Core Pod 配對，確保與特定供應商軟體的相容性。
可靠的流量流動：由於回程流量必須透過相同的網路功能傳回，因此持續性 IP 位址可確保外部系統辨識並回應正確的 Pod，不會中斷通訊。
優點
GKE Pod 的永久 IP 位址可帶來下列優點：
外部身分：如果為 Pod 指派外部永久 IP 位址，外部系統就能持續連線至該 Pod，即使 Pod 在叢集內重新啟動或移動也一樣。這項功能適用於需要外部可探索端點的服務。
可靠的通訊：如果應用程式依附於具有特定 IP 位址的其他資源，則可使用持續性 IP 位址可靠地建立連線。對於具有硬式編碼 IP 位址依附元件的舊版系統或應用程式，持續性 IP 位址非常重要。
舊版遷移：舊版遷移可協助遷移在轉換程序中需要特定 IP 位址的應用程式。
自備 IP 位址 (BYOIP)：BYOIP 可讓您在 GKE 叢集中使用自己擁有的特定 IP 位址範圍，維持控制權。
