本文說明如何解決在 Workload Manager 中使用 SAP 工作負載可觀測性服務時可能遇到的問題。
可觀測性資訊主頁未列出 SAP 系統 ID
設定 Google Cloud's Agent for SAP 以進行可觀測性作業，並授予服務帳戶所有 VM 的必要權限 (這些 VM 裝載 SAP 系統的不同元素，例如中央服務、應用程式伺服器和 SAP HANA 資料庫) 後，系統 ID 就會顯示在 SAP 可觀測性資訊主頁上。如果系統 ID 未列出，請按照下列章節的說明，檢查代理程式設定和記錄。
在「系統總覽」頁面中，檢查系統是否正確識別架構和規模類型。如果這兩個參數有任何一個或全部不正確，則表示Google Cloud的 SAP 代理程式或上傳至 Google Cloud的 SAP 資料有潛在問題。如需進一步分析，請與 Cloud Customer Care 團隊聯絡。請參閱「取得 Google Cloud的 Agent for SAP 支援」。
由於指標 workload/sap/nw/instance/role 或 workload/sap/hana/ha/availability 無法正常運作或遺失，系統無法正確識別與 VM 相關的角色。在「應用程式和資料庫」資訊主頁的 VM 清單中，檢查已識別的 SAP 角色。
以下是各架構類型所需的角色：
集中式架構：核心服務、應用程式伺服器和 SAP HANA 主要伺服器。
分散式架構：核心服務、應用程式伺服器和 SAP HANA 主要伺服器。
分散式架構 (具備高可用性)：核心服務、ERC、應用程式伺服器、SAP HANA 主要伺服器和 SAP HANA 次要伺服器。
清單中的所有 VM 都應指派角色。
請檢查 Cloud Monitoring 中的指標，或使用 timeSeries API 方法，讓 Agent for SAP 推送最新值，確認必要指標具有有效值。如果 Cloud Monitoring 中沒有該指標，或該指標沒有值，則健康狀態會標示為「未指定」，因為資料不足，無法評估該指標。
