Specifications

This page lists specifications for Transfer Appliance models, including usable space capacities, dimensions, power requirements, and packing lists.

Transfer Appliance common specifications

Specification All models
Model description Rugged, tamper-resistant appliance, using SSD technology.
Packaging description Rugged shipping case with rolling wheels and collapsible handle.
Power requirements 100-240 V, 50-60 Hz, 700 W
Network connectivity Data ports:

  • RJ45 (10 Gbps)
  • QSFP+ (40 Gbps) - TA40 and TA300 only

Configuration port: RJ45 (10 Gbps)

Delivery time Overnight (US)
End-to-end cycle time Approximately 3 weeks
Security and encryption
  • Customer-Managed Encryption Key (CMEK)
  • Remote attestation with Secure Boot
  • Unique PIN
Transfer modes
  • NFS share
  • SMB share
  • SSH or SCP transfer
On-device interface Command-line interface
Ease-of-use Automated ingest

Transfer Appliance weights and capacities

Specification TA7 TA40 TA300 TA40F TA300F
Type Rackable Freestanding
Shipping dimensions 22 in x 14 in x 9 in / 560 mm x 360 mm x 230 mm 25.5 in x 24 in x 9.5 in / 647.7 mm x 609.6 mm x 241.3 mm 27 in x 23 in x 10.5 in / 685.8 mm x 584.2 mm x 266.7 mm
Appliance dimensions (H x W x D) 1.7 in x 8.2 in x 14.8 in / 43 mm x 209 mm x 376 mm 3.48 in x 17 in x 21 in / 88.4 mm x 431.8 mm x 533.4 mm 27 in x 23 in x 10.5 in / 685.8 mm x 584.2 mm x 266.7 mm
Shipping weight 30 lbs / 13.6 kg 50 lbs / 23 kg 55 lbs / 25 kg 75 lbs / 34 kg
Appliance weight 7.9 lbs / 3.6 kg 31.7 lbs / 14.4 kg 39 lbs / 17.7 kg 75 lbs / 34 kg
Usable capacity Maximum of 7 TB of encrypted data. Maximum of 40 TB of encrypted data. Maximum of 300 TB of encrypted data. Maximum of 40 TB of encrypted data. Maximum of 300 TB of encrypted data.

Package contents

  • Brochures
  • Connection instructions
  • Packaging instructions
  • Shipping label pouch
  • Shipping tag and zip-tie
  • Tamper-evident tag
  • Cables

Included cables

TA7

Cable photo Cable description
2 x AC Adapter Charger bricks (mounted in a bracket)
2 X C-13 to C-14 power cables
2 X C-13 to NEMA 5-15P cables
1 X RJ-45 Cat 6 ethernet cable

Rackable TA40 and TA300

Cable photo Cable description
A photo depicting a NEMA 5-15P to C13 power cable NEMA 5-15P to C13 power cable (1.8 m / 5.91 ft)
A photo depicting a c14 to c13 power cable C14 to C13 power cable, for connections to the power distribution unit (PDU) (1.5 m / 4.92 ft)
A photo depicting a Category 6 network cable Cat 6 network cable (2.1 m / 6.89 ft)
A photo depicting a QSFP+ twinaxial copper network cable QSFP+ twinaxial copper network cable (3 m / 9.84 ft)
A photo depicting a QSFP+ to 4xSFP+ network cable QSFP+ to 4xSFP+ network cable (3 m / 9.84 ft) - only one (out of 4) SFP+ connector can be used, and link aggregation is not supported
A photo depicting a USB-to-serial adapter cable USB-to-serial adapter cable – use only if instructed by Transfer Appliance Team
A photo depicting a pin-to-socket serial adapter Pin-to-socket serial adapter

Freestanding TA40 and TA300

Cable photo Cable description
A photo depicting a NEMA 5-15P to C13 power cable NEMA 5-15P to C13 power cable (1.8 m / 5.91 ft)
A photo depicting a c14 to c13 power cable C14 to C13 power cable, for connections to the power distribution unit (PDU) (1.5 m / 4.92 ft)
A photo depicting a Category 6 network cable Cat 6 network cable (2.1 m / 6.89 ft)
A photo depicting a QSFP+ twinaxial copper network cable QSFP+ twinaxial copper network cable (3 m / 9.84 ft)
A photo depicting a QSFP+ to 4xSFP+ network cable QSFP+ to 4xSFP+ network cable (3 m / 9.84 ft) - only one (out of 4) SFP+ connector can be used, and link aggregation is not supported
A photo depicting a USB-to-serial adapter cable USB-to-serial adapter cable – use only if instructed by Transfer Appliance Team
A photo depicting a pin-to-socket serial adapter Pin-to-socket serial adapter
