Receiving messages using Pull

Pub/Sub supports both push and pull message delivery. For an overview and comparison of pull and push subscriptions, see the Subscriber Overview. This document describes pull delivery. For a discussion of push delivery, see the Push Subscriber Guide.

Asynchronous Pull

Using asynchronous pulling provides higher throughput in your application, by not requiring your application to block for new messages. Messages can be received in your application using a long running message listener, and acknowledged one message at a time, as shown in the example below. Java, Python, .NET, Go, and Ruby clients use the StreamingPull service API to implement the asynchronous client API efficiently.

Not all client libraries support asynchronously pulling messages. To learn about synchronously pulling messages, see Synchronous Pull.

For more information, see the API Reference documentation in your programming language.

C++

Before trying this sample, follow the C++ setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C++ API reference documentation.

namespace pubsub = google::cloud::pubsub;
using google::cloud::future;
using google::cloud::StatusOr;
[](pubsub::Subscriber subscriber) {
  std::mutex mu;
  std::condition_variable cv;
  int message_count = 0;
  auto session = subscriber.Subscribe(
      [&](pubsub::Message const& m, pubsub::AckHandler h) {
        std::cout << "Received message " << m << "\n";
        std::unique_lock<std::mutex> lk(mu);
        ++message_count;
        lk.unlock();
        cv.notify_one();
        std::move(h).ack();
      });
  // Wait until at least one message has been received.
  std::unique_lock<std::mutex> lk(mu);
  cv.wait(lk, [&message_count] { return message_count > 0; });
  lk.unlock();
  // Cancel the subscription session.
  session.cancel();
  // Wait for the session to complete, no more callbacks can happen after this
  // point.
  auto status = session.get();
  // Report any final status, blocking.
  std::cout << "Message count: " << message_count << ", status: " << status
            << "\n";
}

C#

Before trying this sample, follow the C# setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C# API reference documentation.


using Google.Cloud.PubSub.V1;
using System;
using System.Linq;
using System.Text;
using System.Threading;
using System.Threading.Tasks;

public class PullMessagesAsyncSample
{
    public async Task<int> PullMessagesAsync(string projectId, string subscriptionId, bool acknowledge)
    {
        SubscriptionName subscriptionName = SubscriptionName.FromProjectSubscription(projectId, subscriptionId);
        SubscriberClient subscriber = await SubscriberClient.CreateAsync(subscriptionName);
        // SubscriberClient runs your message handle function on multiple
        // threads to maximize throughput.
        int messageCount = 0;
        Task startTask = subscriber.StartAsync((PubsubMessage message, CancellationToken cancel) =>
        {
            string text = Encoding.UTF8.GetString(message.Data.ToArray());
            Console.WriteLine($"Message {message.MessageId}: {text}");
            Interlocked.Increment(ref messageCount);
            return Task.FromResult(acknowledge ? SubscriberClient.Reply.Ack : SubscriberClient.Reply.Nack);
        });
        // Run for 5 seconds.
        await Task.Delay(5000);
        await subscriber.StopAsync(CancellationToken.None);
        // Lets make sure that the start task finished successfully after the call to stop.
        await startTask;
        return messageCount;
    }
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"
	"sync"

	"cloud.google.com/go/pubsub"
)

func pullMsgs(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}

	// Consume 10 messages.
	var mu sync.Mutex
	received := 0
	sub := client.Subscription(subID)
	cctx, cancel := context.WithCancel(ctx)
	err = sub.Receive(cctx, func(ctx context.Context, msg *pubsub.Message) {
		mu.Lock()
		defer mu.Unlock()
		fmt.Fprintf(w, "Got message: %q\n", string(msg.Data))
		msg.Ack()
		received++
		if received == 10 {
			cancel()
		}
	})
	if err != nil {
		return fmt.Errorf("Receive: %v", err)
	}
	return nil
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.cloud.pubsub.v1.AckReplyConsumer;
import com.google.cloud.pubsub.v1.MessageReceiver;
import com.google.cloud.pubsub.v1.Subscriber;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PubsubMessage;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class SubscribeAsyncExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";

    subscribeAsyncExample(projectId, subscriptionId);
  }

  public static void subscribeAsyncExample(String projectId, String subscriptionId) {
    ProjectSubscriptionName subscriptionName =
        ProjectSubscriptionName.of(projectId, subscriptionId);

    // Instantiate an asynchronous message receiver.
    MessageReceiver receiver =
        (PubsubMessage message, AckReplyConsumer consumer) -> {
          // Handle incoming message, then ack the received message.
          System.out.println("Id: " + message.getMessageId());
          System.out.println("Data: " + message.getData().toStringUtf8());
          consumer.ack();
        };

    Subscriber subscriber = null;
    try {
      subscriber = Subscriber.newBuilder(subscriptionName, receiver).build();
      // Start the subscriber.
      subscriber.startAsync().awaitRunning();
      System.out.printf("Listening for messages on %s:\n", subscriptionName.toString());
      // Allow the subscriber to run for 30s unless an unrecoverable error occurs.
      subscriber.awaitTerminated(30, TimeUnit.SECONDS);
    } catch (TimeoutException timeoutException) {
      // Shut down the subscriber after 30s. Stop receiving messages.
      subscriber.stopAsync();
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';
// const timeout = 60;

// Imports the Google Cloud client library
const {PubSub} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use
const pubSubClient = new PubSub();

function listenForMessages() {
  // References an existing subscription
  const subscription = pubSubClient.subscription(subscriptionName);

  // Create an event handler to handle messages
  let messageCount = 0;
  const messageHandler = message => {
    console.log(`Received message ${message.id}:`);
    console.log(`\tData: ${message.data}`);
    console.log(`\tAttributes: ${message.attributes}`);
    messageCount += 1;

    // "Ack" (acknowledge receipt of) the message
    message.ack();
  };

  // Listen for new messages until timeout is hit
  subscription.on('message', messageHandler);

  setTimeout(() => {
    subscription.removeListener('message', messageHandler);
    console.log(`${messageCount} message(s) received.`);
  }, timeout * 1000);
}

listenForMessages();

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

from concurrent.futures import TimeoutError
from google.cloud import pubsub_v1

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"
# Number of seconds the subscriber should listen for messages
# timeout = 5.0

subscriber = pubsub_v1.SubscriberClient()
# The `subscription_path` method creates a fully qualified identifier
# in the form `projects/{project_id}/subscriptions/{subscription_id}`
subscription_path = subscriber.subscription_path(project_id, subscription_id)

def callback(message):
    print(f"Received {message}.")
    message.ack()

streaming_pull_future = subscriber.subscribe(subscription_path, callback=callback)
print(f"Listening for messages on {subscription_path}..\n")

# Wrap subscriber in a 'with' block to automatically call close() when done.
with subscriber:
    try:
        # When `timeout` is not set, result() will block indefinitely,
        # unless an exception is encountered first.
        streaming_pull_future.result(timeout=timeout)
    except TimeoutError:
        streaming_pull_future.cancel()

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
subscriber   = subscription.listen do |received_message|
  puts "Received message: #{received_message.data}"
  received_message.acknowledge!
end

subscriber.start
# Let the main thread sleep for 60 seconds so the thread for listening
# messages does not quit
sleep 60
subscriber.stop.wait!

Processing Custom Attributes

This sample shows how to pull messages asynchronously and retrieve the custom attributes from metadata:

C++

Before trying this sample, follow the C++ setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C++ API reference documentation.

namespace pubsub = google::cloud::pubsub;
using google::cloud::future;
using google::cloud::StatusOr;
[](pubsub::Subscriber subscriber) {
  std::mutex mu;
  std::condition_variable cv;
  int message_count = 0;
  auto session = subscriber.Subscribe(
      [&](pubsub::Message const& m, pubsub::AckHandler h) {
        std::cout << "Received message with attributes:\n";
        for (auto const& kv : m.attributes()) {
          std::cout << "  " << kv.first << ": " << kv.second << "\n";
        }
        std::unique_lock<std::mutex> lk(mu);
        ++message_count;
        lk.unlock();
        cv.notify_one();
        std::move(h).ack();
      });
  // Most applications would just release the `session` object at this point,
  // but we want to gracefully close down this example.
  std::unique_lock<std::mutex> lk(mu);
  cv.wait(lk, [&message_count] { return message_count > 0; });
  lk.unlock();
  session.cancel();
  auto status = session.get();
  std::cout << "Message count: " << message_count << ", status: " << status
            << "\n";
}

C#

Before trying this sample, follow the C# setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C# API reference documentation.


using Google.Cloud.PubSub.V1;
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading;
using System.Threading.Tasks;

public class PullMessagesWithCustomAttributesAsyncSample
{
    public async Task<List<PubsubMessage>> PullMessagesWithCustomAttributesAsync(string projectId, string subscriptionId, bool acknowledge)
    {
        SubscriptionName subscriptionName = SubscriptionName.FromProjectSubscription(projectId, subscriptionId);

        SubscriberClient subscriber = await SubscriberClient.CreateAsync(subscriptionName);
        var messages = new List<PubsubMessage>();
        Task startTask = subscriber.StartAsync((PubsubMessage message, CancellationToken cancel) =>
        {
            messages.Add(message);
            string text = Encoding.UTF8.GetString(message.Data.ToArray());
            Console.WriteLine($"Message {message.MessageId}: {text}");
            if (message.Attributes != null)
            {
                foreach (var attribute in message.Attributes)
                {
                    Console.WriteLine($"{attribute.Key} = {attribute.Value}");
                }
            }
            return Task.FromResult(acknowledge ? SubscriberClient.Reply.Ack : SubscriberClient.Reply.Nack);
        });
        // Run for 7 seconds.
        await Task.Delay(7000);
        await subscriber.StopAsync(CancellationToken.None);
        // Lets make sure that the start task finished successfully after the call to stop.
        await startTask;
        return messages;
    }
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"
	"time"

	"cloud.google.com/go/pubsub"
)

func pullMsgsCustomAttributes(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}
	defer client.Close()

	sub := client.Subscription(subID)

	// Receive messages for 10 seconds.
	ctx, cancel := context.WithTimeout(ctx, 10*time.Second)
	defer cancel()

	// Create a channel to handle messages to as they come in.
	cm := make(chan *pubsub.Message)
	defer close(cm)

	// Handle individual messages in a goroutine.
	go func() {
		for msg := range cm {
			fmt.Fprintf(w, "Got message :%q\n", string(msg.Data))
			fmt.Fprintln(w, "Attributes:")
			for key, value := range msg.Attributes {
				fmt.Fprintf(w, "%s = %s", key, value)
			}
			msg.Ack()
		}
	}()

	// Receive blocks until the context is cancelled or an error occurs.
	err = sub.Receive(ctx, func(ctx context.Context, msg *pubsub.Message) {
		cm <- msg
	})
	if err != nil {
		return fmt.Errorf("Receive: %v", err)
	}

	return nil
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.cloud.pubsub.v1.AckReplyConsumer;
import com.google.cloud.pubsub.v1.MessageReceiver;
import com.google.cloud.pubsub.v1.Subscriber;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PubsubMessage;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class SubscribeWithCustomAttributesExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";

    subscribeWithCustomAttributesExample(projectId, subscriptionId);
  }

  public static void subscribeWithCustomAttributesExample(String projectId, String subscriptionId) {
    ProjectSubscriptionName subscriptionName =
        ProjectSubscriptionName.of(projectId, subscriptionId);

    // Instantiate an asynchronous message receiver.
    MessageReceiver receiver =
        (PubsubMessage message, AckReplyConsumer consumer) -> {
          // Handle incoming message, then ack the received message.
          System.out.println("Id: " + message.getMessageId());
          System.out.println("Data: " + message.getData().toStringUtf8());
          // Print message attributes.
          message
              .getAttributesMap()
              .forEach((key, value) -> System.out.println(key + " = " + value));
          consumer.ack();
        };

    Subscriber subscriber = null;
    try {
      subscriber = Subscriber.newBuilder(subscriptionName, receiver).build();
      // Start the subscriber.
      subscriber.startAsync().awaitRunning();
      System.out.printf("Listening for messages on %s:\n", subscriptionName.toString());
      // Allow the subscriber to run for 30s unless an unrecoverable error occurs.
      subscriber.awaitTerminated(30, TimeUnit.SECONDS);
    } catch (TimeoutException timeoutException) {
      // Shut down the subscriber after 30s. Stop receiving messages.
      subscriber.stopAsync();
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';
// const timeout = 60;

// Imports the Google Cloud client library
const {PubSub} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use
const pubSubClient = new PubSub();

async function listenWithCustomAttributes() {
  // References an existing subscription, e.g. "my-subscription"
  const subscription = pubSubClient.subscription(subscriptionName);

  // Create an event handler to handle messages
  const messageHandler = message => {
    console.log(
      `Received message: id ${message.id}, data ${
        message.data
      }, attributes: ${JSON.stringify(message.attributes)}`
    );

    // "Ack" (acknowledge receipt of) the message
    message.ack();
  };

  // Listen for new messages until timeout is hit
  subscription.on('message', messageHandler);
  setTimeout(() => {
    subscription.removeListener('message', messageHandler);
  }, timeout * 1000);
}

listenWithCustomAttributes();

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

from concurrent.futures import TimeoutError
from google.cloud import pubsub_v1

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"
# Number of seconds the subscriber should listen for messages
# timeout = 5.0

subscriber = pubsub_v1.SubscriberClient()
subscription_path = subscriber.subscription_path(project_id, subscription_id)

def callback(message):
    print(f"Received {message.data}.")
    if message.attributes:
        print("Attributes:")
        for key in message.attributes:
            value = message.attributes.get(key)
            print(f"{key}: {value}")
    message.ack()

streaming_pull_future = subscriber.subscribe(subscription_path, callback=callback)
print(f"Listening for messages on {subscription_path}..\n")

# Wrap subscriber in a 'with' block to automatically call close() when done.
with subscriber:
    try:
        # When `timeout` is not set, result() will block indefinitely,
        # unless an exception is encountered first.
        streaming_pull_future.result(timeout=timeout)
    except TimeoutError:
        streaming_pull_future.cancel()

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
subscriber   = subscription.listen do |received_message|
  puts "Received message: #{received_message.data}"
  unless received_message.attributes.empty?
    puts "Attributes:"
    received_message.attributes.each do |key, value|
      puts "#{key}: #{value}"
    end
  end
  received_message.acknowledge!
end

subscriber.start
# Let the main thread sleep for 60 seconds so the thread for listening
# messages does not quit
sleep 60
subscriber.stop.wait!

Listening for Errors

This sample shows how to handle errors that arise when subscribing to messages:

C++

Before trying this sample, follow the C++ setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C++ API reference documentation.

namespace pubsub = google::cloud::pubsub;
using google::cloud::future;
using google::cloud::StatusOr;
[](pubsub::Subscriber subscriber) {
  std::mutex mu;
  std::condition_variable cv;
  bool done = false;
  int message_count = 0;
  auto session =
      subscriber
          .Subscribe([&](pubsub::Message const& m, pubsub::AckHandler h) {
            std::cout << "Received message " << m << "\n";
            std::unique_lock<std::mutex> lk(mu);
            ++message_count;
            done = true;
            lk.unlock();
            cv.notify_one();
            std::move(h).ack();
          })
          // Setup an error handler for the subscription session
          .then([&](future<google::cloud::Status> f) {
            std::cout << "Subscription session result: " << f.get() << "\n";
            std::unique_lock<std::mutex> lk(mu);
            done = true;
            cv.notify_one();
          });
  // Most applications would just release the `session` object at this point,
  // but we want to gracefully close down this example.
  std::unique_lock<std::mutex> lk(mu);
  cv.wait(lk, [&done] { return done; });
  lk.unlock();
  session.cancel();
  session.get();
  std::cout << "Message count:" << message_count << "\n";
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"

	"cloud.google.com/go/pubsub"
)

func pullMsgsError(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}

	// If the service returns a non-retryable error, Receive returns that error after
	// all of the outstanding calls to the handler have returned.
	err = client.Subscription(subID).Receive(ctx, func(ctx context.Context, msg *pubsub.Message) {
		fmt.Fprintf(w, "Got message: %q\n", string(msg.Data))
		msg.Ack()
	})
	if err != nil {
		return fmt.Errorf("Receive: %v", err)
	}
	return nil
}

Java

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.


import com.google.api.gax.core.ExecutorProvider;
import com.google.api.gax.core.InstantiatingExecutorProvider;
import com.google.cloud.pubsub.v1.AckReplyConsumer;
import com.google.cloud.pubsub.v1.MessageReceiver;
import com.google.cloud.pubsub.v1.Subscriber;
import com.google.common.util.concurrent.MoreExecutors;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PubsubMessage;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class SubscribeWithErrorListenerExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";

    subscribeWithErrorListenerExample(projectId, subscriptionId);
  }

  public static void subscribeWithErrorListenerExample(String projectId, String subscriptionId) {
    ProjectSubscriptionName subscriptionName =
        ProjectSubscriptionName.of(projectId, subscriptionId);

    // Instantiate an asynchronous message receiver.
    MessageReceiver receiver =
        (PubsubMessage message, AckReplyConsumer consumer) -> {
          // Handle incoming message, then ack the received message.
          System.out.println("Id: " + message.getMessageId());
          System.out.println("Data: " + message.getData().toStringUtf8());
          consumer.ack();
        };

    Subscriber subscriber = null;
    try {
      // Provides an executor service for processing messages.
      ExecutorProvider executorProvider =
          InstantiatingExecutorProvider.newBuilder().setExecutorThreadCount(4).build();

      subscriber =
          Subscriber.newBuilder(subscriptionName, receiver)
              .setExecutorProvider(executorProvider)
              .build();

      // Listen for unrecoverable failures. Rebuild a subscriber and restart subscribing
      // when the current subscriber encounters permanent errors.
      subscriber.addListener(
          new Subscriber.Listener() {
            public void failed(Subscriber.State from, Throwable failure) {
              System.out.println(failure.getStackTrace());
              if (!executorProvider.getExecutor().isShutdown()) {
                subscribeWithErrorListenerExample(projectId, subscriptionId);
              }
            }
          },
          MoreExecutors.directExecutor());

      // Start the subscriber.
      subscriber.startAsync().awaitRunning();
      System.out.printf("Listening for messages on %s:\n", subscriptionName.toString());
      // Allow the subscriber to run for 30s unless an unrecoverable error occurs.
      subscriber.awaitTerminated(30, TimeUnit.SECONDS);
    } catch (TimeoutException timeoutException) {
      // Shut down the subscriber after 30s. Stop receiving messages.
      subscriber.stopAsync();
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';
// const timeout = 10;

// Imports the Google Cloud client library
const {PubSub} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use
const pubSubClient = new PubSub();

function listenForErrors() {
  // References an existing subscription
  const subscription = pubSubClient.subscription(subscriptionName);

  // Create an event handler to handle messages
  const messageHandler = function (message) {
    // Do something with the message
    console.log(`Message: ${message}`);

    // "Ack" (acknowledge receipt of) the message
    message.ack();
  };

  // Create an event handler to handle errors
  const errorHandler = function (error) {
    // Do something with the error
    console.error(`ERROR: ${error}`);
    throw error;
  };

  // Listen for new messages/errors until timeout is hit
  subscription.on('message', messageHandler);
  subscription.on('error', errorHandler);

  setTimeout(() => {
    subscription.removeListener('message', messageHandler);
    subscription.removeListener('error', errorHandler);
  }, timeout * 1000);
}

listenForErrors();

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

from google.cloud import pubsub_v1

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"
# Number of seconds the subscriber should listen for messages
# timeout = 5.0

subscriber = pubsub_v1.SubscriberClient()
subscription_path = subscriber.subscription_path(project_id, subscription_id)

def callback(message):
    print(f"Received {message}.")
    message.ack()

streaming_pull_future = subscriber.subscribe(subscription_path, callback=callback)
print(f"Listening for messages on {subscription_path}..\n")

# Wrap subscriber in a 'with' block to automatically call close() when done.
with subscriber:
    # When `timeout` is not set, result() will block indefinitely,
    # unless an exception is encountered first.
    try:
        streaming_pull_future.result(timeout=timeout)
    except Exception as e:
        streaming_pull_future.cancel()
        print(
            f"Listening for messages on {subscription_path} threw an exception: {e}."
        )

Ruby

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
subscriber   = subscription.listen do |received_message|
  puts "Received message: #{received_message.data}"
  received_message.acknowledge!
end
# Propagate expection from child threads to the main thread as soon as it is
# raised. Exceptions happened in the callback thread are collected in the
# callback thread pool and do not propagate to the main thread
Thread.abort_on_exception = true

begin
  subscriber.start
  # Let the main thread sleep for 60 seconds so the thread for listening
  # messages does not quit
  sleep 60
  subscriber.stop.wait!
rescue Exception => e
  puts "Exception #{e.inspect}: #{e.message}"
  raise "Stopped listening for messages."
end

Message Flow Control

Your subscriber client might process and acknowledge messages more slowly than Pub/Sub sends them to the client. In this case:

  • It's possible that one client could have a backlog of messages because it doesn't have the capacity to process the volume of incoming messages, but another client on the network does have that capacity. The second client could reduce the subscription's backlog, but it doesn't get the chance to do so because the first client maintains a lease on the messages that it receives. This reduces the overall rate of processing because messages get stuck on the first client.

  • Because the client library repeatedly extends the acknowledgement deadline for backlogged messages, those messages continue to consume memory, CPU, and bandwidth resources. As such, the subscriber client might run out of resources (such as memory). This can adversely impact the throughput and latency of processing messages.

To mitigate the issues above, use the flow control features of the subscriber to control the rate at which the subscriber receives messages. These flow control features are illustrated in the following samples:

C++

Before trying this sample, follow the C++ setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C++ API reference documentation.

namespace pubsub = google::cloud::pubsub;
using google::cloud::future;
using google::cloud::StatusOr;
[](std::string project_id, std::string subscription_id) {
  // Change the flow control watermarks, by default the client library uses
  // 0 and 1,000 for the message count watermarks, and 0 and 10MiB for the
  // size watermarks. Recall that the library stops requesting messages if
  // any of the high watermarks are reached, and the library resumes
  // requesting messages when *both* low watermarks are reached.
  auto constexpr kMiB = 1024 * 1024L;
  auto subscriber = pubsub::Subscriber(pubsub::MakeSubscriberConnection(
      pubsub::Subscription(std::move(project_id), std::move(subscription_id)),
      pubsub::SubscriberOptions{}
          .set_max_outstanding_messages(1000)
          .set_max_outstanding_bytes(8 * kMiB)));

  std::mutex mu;
  std::condition_variable cv;
  int count = 0;
  auto constexpr kExpectedMessageCount = 4;
  auto handler = [&](pubsub::Message const& m, pubsub::AckHandler h) {
    std::move(h).ack();
    {
      std::lock_guard<std::mutex> lk(mu);
      std::cout << "Received message [" << count << "] " << m.data() << "\n";
      if (++count < kExpectedMessageCount) return;
    }
    cv.notify_one();
  };
  auto session = subscriber.Subscribe(std::move(handler));
  {
    std::unique_lock<std::mutex> lk(mu);
    cv.wait(lk, [&] { return count >= kExpectedMessageCount; });
  }
  session.cancel();
  auto status = session.get();
  std::cout << "Message count: " << count << ", status: " << status << "\n";
}

C#

Before trying this sample, follow the C# setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C# API reference documentation.


using Google.Api.Gax;
using Google.Cloud.PubSub.V1;
using System;
using System.Linq;
using System.Text;
using System.Threading;
using System.Threading.Tasks;

public class PullMessagesWithFlowControlAsyncSample
{
    public async Task<int> PullMessagesWithFlowControlAsync(string projectId, string subscriptionId, bool acknowledge)
    {
        SubscriptionName subscriptionName = SubscriptionName.FromProjectSubscription(projectId, subscriptionId);
        int messageCount = 0;
        SubscriberClient subscriber = await SubscriberClient.CreateAsync(subscriptionName,
            settings: new SubscriberClient.Settings()
            {
                AckExtensionWindow = TimeSpan.FromSeconds(4),
                AckDeadline = TimeSpan.FromSeconds(10),
                FlowControlSettings = new FlowControlSettings(maxOutstandingElementCount: 100, maxOutstandingByteCount: 10240)
            });
        // SubscriberClient runs your message handle function on multiple
        // threads to maximize throughput.
        Task startTask = subscriber.StartAsync((PubsubMessage message, CancellationToken cancel) =>
        {
            string text = Encoding.UTF8.GetString(message.Data.ToArray());
            Console.WriteLine($"Message {message.MessageId}: {text}");
            Interlocked.Increment(ref messageCount);
            return Task.FromResult(acknowledge ? SubscriberClient.Reply.Ack : SubscriberClient.Reply.Nack);
        });
        // Run for 5 seconds.
        await Task.Delay(5000);
        await subscriber.StopAsync(CancellationToken.None);
        // Lets make sure that the start task finished successfully after the call to stop.
        await startTask;
        return messageCount;
    }
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"

	"cloud.google.com/go/pubsub"
)

func pullMsgsSettings(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}

	sub := client.Subscription(subID)
	sub.ReceiveSettings.Synchronous = true
	// MaxOutstandingMessages is the maximum number of unprocessed messages the
	// client will pull from the server before pausing.
	//
	// This is only guaranteed when ReceiveSettings.Synchronous is set to true.
	// When Synchronous is set to false, the StreamingPull RPC is used which
	// can pull a single large batch of messages at once that is greater than
	// MaxOustandingMessages before pausing. For more info, see
	// https://cloud.google.com/pubsub/docs/pull#streamingpull_dealing_with_large_backlogs_of_small_messages.
	sub.ReceiveSettings.MaxOutstandingMessages = 10
	// MaxOutstandingBytes is the maximum size of unprocessed messages,
	// that the client will pull from the server before pausing. Similar
	// to MaxOutstandingMessages, this may be exceeded with a large batch
	// of messages since we cannot control the size of a batch of messages
	// from the server (even with the synchronous Pull RPC).
	sub.ReceiveSettings.MaxOutstandingBytes = 1e10
	err = sub.Receive(ctx, func(ctx context.Context, msg *pubsub.Message) {
		fmt.Fprintf(w, "Got message: %q\n", string(msg.Data))
		msg.Ack()
	})
	if err != nil {
		return fmt.Errorf("Receive: %v", err)
	}
	return nil
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.api.gax.batching.FlowControlSettings;
import com.google.cloud.pubsub.v1.AckReplyConsumer;
import com.google.cloud.pubsub.v1.MessageReceiver;
import com.google.cloud.pubsub.v1.Subscriber;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PubsubMessage;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class SubscribeWithFlowControlSettingsExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";

    subscribeWithFlowControlSettingsExample(projectId, subscriptionId);
  }

  public static void subscribeWithFlowControlSettingsExample(
      String projectId, String subscriptionId) {
    ProjectSubscriptionName subscriptionName =
        ProjectSubscriptionName.of(projectId, subscriptionId);

    // Instantiate an asynchronous message receiver.
    MessageReceiver receiver =
        (PubsubMessage message, AckReplyConsumer consumer) -> {
          // Handle incoming message, then ack the received message.
          System.out.println("Id: " + message.getMessageId());
          System.out.println("Data: " + message.getData().toStringUtf8());
          consumer.ack();
        };

    Subscriber subscriber = null;

    // The subscriber will pause the message stream and stop receiving more messsages from the
    // server if any one of the conditions is met.
    FlowControlSettings flowControlSettings =
        FlowControlSettings.newBuilder()
            // 1,000 outstanding messages. Must be >0. It controls the maximum number of messages
            // the subscriber receives before pausing the message stream.
            .setMaxOutstandingElementCount(1000L)
            // 100 MiB. Must be >0. It controls the maximum size of messages the subscriber
            // receives before pausing the message stream.
            .setMaxOutstandingRequestBytes(100L * 1024L * 1024L)
            .build();

    try {
      subscriber =
          Subscriber.newBuilder(subscriptionName, receiver)
              .setFlowControlSettings(flowControlSettings)
              .build();

      // Start the subscriber.
      subscriber.startAsync().awaitRunning();
      System.out.printf("Listening for messages on %s:\n", subscriptionName.toString());
      // Allow the subscriber to run for 30s unless an unrecoverable error occurs.
      subscriber.awaitTerminated(30, TimeUnit.SECONDS);
    } catch (TimeoutException timeoutException) {
      // Shut down the subscriber after 30s. Stop receiving messages.
      subscriber.stopAsync();
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';
// const maxInProgress = 5;
// const timeout = 10;

// Imports the Google Cloud client library
const {PubSub} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use
const pubSubClient = new PubSub();

async function subscribeWithFlowControlSettings() {
  const subscriberOptions = {
    flowControl: {
      maxMessages: maxInProgress,
    },
  };

  // References an existing subscription.
  // Note that flow control settings are not persistent across subscribers.
  const subscription = pubSubClient.subscription(
    subscriptionName,
    subscriberOptions
  );

  console.log(
    `Subscriber to subscription ${subscription.name} is ready to receive messages at a controlled volume of ${maxInProgress} messages.`
  );

  const messageHandler = message => {
    console.log(`Received message: ${message.id}`);
    console.log(`\tData: ${message.data}`);
    console.log(`\tAttributes: ${message.attributes}`);

    // "Ack" (acknowledge receipt of) the message
    message.ack();
  };

  subscription.on('message', messageHandler);

  setTimeout(() => {
    subscription.close();
  }, timeout * 1000);
}

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

from concurrent.futures import TimeoutError
from google.cloud import pubsub_v1

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"
# Number of seconds the subscriber should listen for messages
# timeout = 5.0

subscriber = pubsub_v1.SubscriberClient()
subscription_path = subscriber.subscription_path(project_id, subscription_id)

def callback(message):
    print(f"Received {message.data}.")
    message.ack()

# Limit the subscriber to only have ten outstanding messages at a time.
flow_control = pubsub_v1.types.FlowControl(max_messages=10)

streaming_pull_future = subscriber.subscribe(
    subscription_path, callback=callback, flow_control=flow_control
)
print(f"Listening for messages on {subscription_path}..\n")

# Wrap subscriber in a 'with' block to automatically call close() when done.
with subscriber:
    try:
        # When `timeout` is not set, result() will block indefinitely,
        # unless an exception is encountered first.
        streaming_pull_future.result(timeout=timeout)
    except TimeoutError:
        streaming_pull_future.cancel()

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
subscriber   = subscription.listen inventory: 10 do |received_message|
  puts "Received message: #{received_message.data}"
  received_message.acknowledge!
end

subscriber.start
# Let the main thread sleep for 60 seconds so the thread for listening
# messages does not quit
sleep 60
subscriber.stop.wait!

More generally, the need for flow control indicates that messages are being published at a higher rate than they are being consumed. If this is a persistent state, rather than a transient spike in message volume, consider increasing the number of subscriber client instances.

Concurrency Control

Support for concurrency depends on your programming language. For language implementations that support parallel threads, such as Java and Go, the client libraries make a default choice for the number of threads. This choice may not be optimal for your application. For example, if you find that your subscriber application is not keeping up with the incoming message volume but is not CPU-bound, you should increase the thread count. For CPU-intensive message processing operations, reducing the number of threads might be appropriate.

The following sample illustrates how to control concurrency in a subscriber:

C++

Before trying this sample, follow the C++ setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C++ API reference documentation.

namespace pubsub = google::cloud::pubsub;
using google::cloud::future;
using google::cloud::StatusOr;
[](std::string project_id, std::string subscription_id) {
  // Create a subscriber with 16 threads handling I/O work, by default the
  // library creates `std::thread::hardware_concurrency()` threads.
  auto subscriber = pubsub::Subscriber(pubsub::MakeSubscriberConnection(
      pubsub::Subscription(std::move(project_id), std::move(subscription_id)),
      pubsub::SubscriberOptions{}.set_max_concurrency(8),
      pubsub::ConnectionOptions{}.set_background_thread_pool_size(16)));

  std::mutex mu;
  std::condition_variable cv;
  int count = 0;
  auto constexpr kExpectedMessageCount = 4;
  auto handler = [&](pubsub::Message const& m, pubsub::AckHandler h) {
    // This handler executes in the I/O threads, applications could use,
    // std::async(), a thread-pool,
    // google::cloud::CompletionQueue::RunAsync(), or any other mechanism to
    // transfer the execution to other threads.
    std::cout << "Received message " << m << "\n";
    std::move(h).ack();
    {
      std::lock_guard<std::mutex> lk(mu);
      if (++count < kExpectedMessageCount) return;
    }
    cv.notify_one();
  };

  // Create a subscription where up to 8 messages are handled concurrently. By
  // default the library uses `std::thread::hardware_concurrency()` as the
  // maximum number of concurrent callbacks.
  auto session = subscriber.Subscribe(std::move(handler));
  {
    std::unique_lock<std::mutex> lk(mu);
    cv.wait(lk, [&] { return count >= kExpectedMessageCount; });
  }
  session.cancel();
  auto status = session.get();
  std::cout << "Message count: " << count << ", status: " << status << "\n";
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"
	"runtime"
	"sync/atomic"
	"time"

	"cloud.google.com/go/pubsub"
)

func pullMsgsConcurrenyControl(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}
	defer client.Close()

	sub := client.Subscription(subID)
	// Must set ReceiveSettings.Synchronous to false (or leave as default) to enable
	// concurrency settings. Otherwise, NumGoroutines will be set to 1.
	sub.ReceiveSettings.Synchronous = false
	// NumGoroutines is the number of goroutines sub.Receive will spawn to pull
	// messages concurrently.
	sub.ReceiveSettings.NumGoroutines = runtime.NumCPU()

	// Receive messages for 10 seconds.
	ctx, cancel := context.WithTimeout(ctx, 10*time.Second)
	defer cancel()

	var counter int32

	// Receive blocks until the context is cancelled or an error occurs.
	err = sub.Receive(ctx, func(_ context.Context, msg *pubsub.Message) {
		// The message handler passed to Receive may be called concurrently
		// so it's okay to process the messages concurrently but make sure
		// to synchronize access to shared memory.
		atomic.AddInt32(&counter, 1)
		msg.Ack()
	})
	if err != nil {
		return fmt.Errorf("pubsub: Receive returned error: %v", err)
	}
	fmt.Fprintf(w, "Received %d messages\n", counter)

	return nil
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.api.gax.core.ExecutorProvider;
import com.google.api.gax.core.InstantiatingExecutorProvider;
import com.google.cloud.pubsub.v1.AckReplyConsumer;
import com.google.cloud.pubsub.v1.MessageReceiver;
import com.google.cloud.pubsub.v1.Subscriber;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PubsubMessage;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.TimeoutException;

public class SubscribeWithConcurrencyControlExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";

    subscribeWithConcurrencyControlExample(projectId, subscriptionId);
  }

  public static void subscribeWithConcurrencyControlExample(
      String projectId, String subscriptionId) {
    ProjectSubscriptionName subscriptionName =
        ProjectSubscriptionName.of(projectId, subscriptionId);

    // Instantiate an asynchronous message receiver.
    MessageReceiver receiver =
        (PubsubMessage message, AckReplyConsumer consumer) -> {
          // Handle incoming message, then ack the received message.
          System.out.println("Id: " + message.getMessageId());
          System.out.println("Data: " + message.getData().toStringUtf8());
          consumer.ack();
        };

    Subscriber subscriber = null;
    try {
      // Provides an executor service for processing messages. The default `executorProvider` used
      // by the subscriber has a default thread count of 5.
      ExecutorProvider executorProvider =
          InstantiatingExecutorProvider.newBuilder().setExecutorThreadCount(4).build();

      // `setParallelPullCount` determines how many StreamingPull streams the subscriber will open
      // to receive message. It defaults to 1. `setExecutorProvider` configures an executor for the
      // subscriber to process messages. Here, the subscriber is configured to open 2 streams for
      // receiving messages, each stream creates a new executor with 4 threads to help process the
      // message callbacks. In total 2x4=8 threads are used for message processing.
      subscriber =
          Subscriber.newBuilder(subscriptionName, receiver)
              .setParallelPullCount(2)
              .setExecutorProvider(executorProvider)
              .build();

      // Start the subscriber.
      subscriber.startAsync().awaitRunning();
      System.out.printf("Listening for messages on %s:\n", subscriptionName.toString());
      // Allow the subscriber to run for 30s unless an unrecoverable error occurs.
      subscriber.awaitTerminated(30, TimeUnit.SECONDS);
    } catch (TimeoutException timeoutException) {
      // Shut down the subscriber after 30s. Stop receiving messages.
      subscriber.stopAsync();
    }
  }
}

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
# Use 2 threads for streaming, 4 threads for executing callbacks and 2 threads
# for sending acknowledgements and/or delays
subscriber   = subscription.listen streams: 2, threads: {
  callback: 4,
  push:     2
} do |received_message|
  puts "Received message: #{received_message.data}"
  received_message.acknowledge!
end

subscriber.start
# Let the main thread sleep for 60 seconds so the thread for listening
# messages does not quit
sleep 60
subscriber.stop.wait!

Support for concurrency depends on your programming language. Refer to the API Reference documentation for more information.

StreamingPull

The Pub/Sub service has two APIs for retrieving messages:

Where possible, the Cloud Client libraries use StreamingPull for maximum throughput and lowest latency. Although you might never use the StreamingPull API directly, it is important to understand some crucial properties of StreamingPull and how it differs from the more traditional Pull method.

The Pull method relies on a request/response model:

  1. The client sends a request to the server for messages.
  2. The server replies with zero or more messages and closes the connection.

The StreamingPull service API relies on a persistent bidirectional connection to receive multiple messages as they become available:

  1. The client sends a request to the server to establish a connection.
  2. The server continuously sends messages to the connected client.
  3. The connection is eventually terminated either by the client or the server.

You provide a callback to the subscriber and the subscriber asynchronously runs the callback for each message. If a subscriber receives messages with the same ordering key, the client libraries sequentially run the callback. The Pub/Sub service delivers these messages to the same subscriber on a best-effort basis.

StreamingPull has a 100% error rate (this is to be expected)

StreamingPull streams are always terminated with a non-OK status. Note that, unlike in regular RPCs, the status here is simply an indication that the stream has been broken, not that requests are failing. Therefore, while the StreamingPull API may have a seemingly surprising 100% error rate, this is by design.

Diagnosing StreamingPull errors

Because StreamingPull streams always terminate with an error, it isn't helpful to examine stream termination metrics while diagnosing errors. Rather, focus on the StreamingPull message operation metric (subscription/streaming_pull_message_operation_count). Look for these errors:

  • FAILED_PRECONDITION errors can occur in these cases:
    • Pub/Sub attempts to decrypt a message with a disabled Cloud KMS key.
    • Subscriptions can be temporarily suspended if there are messages in the subscription backlog that are encrypted with a disabled Cloud KMS key.
  • UNAVAILABLE errors

StreamingPull: Dealing with large backlogs of small messages

The gRPC StreamingPull stack is optimized for high throughput and therefore buffers messages. This can have some consequences if you are attempting to process large backlogs of small messages (rather than a steady stream of new messages). Under these conditions, you may see messages delivered multiple times and they may not be load balanced effectively across clients.

The buffer between the Pub/Sub service and the client library user space is roughly 10MB. To understand the impact of this buffer on client library behavior, consider this example:

  • There is a backlog of 10,000 1KB messages on a subscription.
  • Each message takes 1 second to process sequentially, by a single-threaded client instance.
  • The first client instance to establish a StreamingPull connection to the service for that subscription will fill its buffer with all 10,000 messages.
  • It takes 10,000 seconds (almost 3 hours) to process the buffer.
  • In that time, some of the buffered messages exceed their acknowledgement deadline and are re-sent to the same client, resulting in duplicates.
  • When multiple client instances are running, the messages stuck in the one client's buffer will not be available to any client instances.

This situation will not occur if the messages are arriving at a steady rate (rather than as a single, large batch): the service never has the entire 10MB of messages at a time and so is able to effectively load balance messages across multiple subscribers.

To address this situation, either use a push subscription or the Pull API, currently available in some of the Cloud Client Libraries (see the Synchronous Pull section) and all API Client libraries. To learn more, see the Client Libraries documentation.

Synchronous Pull

There are cases when the asynchronous Pull is not a perfect fit for your application. For example, the application logic might rely on a polling pattern to retrieve messages or require a precise cap on a number of messages retrieved by the client at any given time. To support such applications, the service supports a synchronous Pull method.

Here is some sample code to pull and acknowledge a fixed number of messages:

C#

Before trying this sample, follow the C# setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C# API reference documentation.


using Google.Cloud.PubSub.V1;
using Grpc.Core;
using System;
using System.Linq;
using System.Text;
using System.Threading;

public class PullMessagesSyncSample
{
    public int PullMessagesSync(string projectId, string subscriptionId, bool acknowledge)
    {
        SubscriptionName subscriptionName = SubscriptionName.FromProjectSubscription(projectId, subscriptionId);
        SubscriberServiceApiClient subscriberClient = SubscriberServiceApiClient.Create();
        int messageCount = 0;
        try
        {
            // Pull messages from server,
            // allowing an immediate response if there are no messages.
            PullResponse response = subscriberClient.Pull(subscriptionName, returnImmediately: false, maxMessages: 20);
            // Print out each received message.
            foreach (ReceivedMessage msg in response.ReceivedMessages)
            {
                string text = Encoding.UTF8.GetString(msg.Message.Data.ToArray());
                Console.WriteLine($"Message {msg.Message.MessageId}: {text}");
                Interlocked.Increment(ref messageCount);
            }
            // If acknowledgement required, send to server.
            if (acknowledge && messageCount > 0)
            {
                subscriberClient.Acknowledge(subscriptionName, response.ReceivedMessages.Select(msg => msg.AckId));
            }
        }
        catch (RpcException ex) when (ex.Status.StatusCode == StatusCode.Unavailable)
        {
            // UNAVAILABLE due to too many concurrent pull requests pending for the given subscription.
        }
        return messageCount;
    }
}

Go

Before trying this sample, follow the Go setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Go API reference documentation.

import (
	"context"
	"fmt"
	"io"
	"time"

	"google.golang.org/grpc/codes"
	"google.golang.org/grpc/status"

	"cloud.google.com/go/pubsub"
)

func pullMsgsSync(w io.Writer, projectID, subID string) error {
	// projectID := "my-project-id"
	// subID := "my-sub"
	ctx := context.Background()
	client, err := pubsub.NewClient(ctx, projectID)
	if err != nil {
		return fmt.Errorf("pubsub.NewClient: %v", err)
	}
	defer client.Close()

	sub := client.Subscription(subID)

	// Turn on synchronous mode. This makes the subscriber use the Pull RPC rather
	// than the StreamingPull RPC, which is useful for guaranteeing MaxOutstandingMessages,
	// the max number of messages the client will hold in memory at a time.
	sub.ReceiveSettings.Synchronous = true
	sub.ReceiveSettings.MaxOutstandingMessages = 10

	// Receive messages for 5 seconds.
	ctx, cancel := context.WithTimeout(ctx, 5*time.Second)
	defer cancel()

	// Create a channel to handle messages to as they come in.
	cm := make(chan *pubsub.Message)
	defer close(cm)
	// Handle individual messages in a goroutine.
	go func() {
		for msg := range cm {
			fmt.Fprintf(w, "Got message :%q\n", string(msg.Data))
			msg.Ack()
		}
	}()

	// Receive blocks until the passed in context is done.
	err = sub.Receive(ctx, func(ctx context.Context, msg *pubsub.Message) {
		cm <- msg
	})
	if err != nil && status.Code(err) != codes.Canceled {
		return fmt.Errorf("Receive: %v", err)
	}

	return nil
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.cloud.pubsub.v1.stub.GrpcSubscriberStub;
import com.google.cloud.pubsub.v1.stub.SubscriberStub;
import com.google.cloud.pubsub.v1.stub.SubscriberStubSettings;
import com.google.pubsub.v1.AcknowledgeRequest;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PullRequest;
import com.google.pubsub.v1.PullResponse;
import com.google.pubsub.v1.ReceivedMessage;
import java.io.IOException;
import java.util.ArrayList;
import java.util.List;

public class SubscribeSyncExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";
    Integer numOfMessages = 10;

    subscribeSyncExample(projectId, subscriptionId, numOfMessages);
  }

  public static void subscribeSyncExample(
      String projectId, String subscriptionId, Integer numOfMessages) throws IOException {
    SubscriberStubSettings subscriberStubSettings =
        SubscriberStubSettings.newBuilder()
            .setTransportChannelProvider(
                SubscriberStubSettings.defaultGrpcTransportProviderBuilder()
                    .setMaxInboundMessageSize(20 * 1024 * 1024) // 20MB (maximum message size).
                    .build())
            .build();

    try (SubscriberStub subscriber = GrpcSubscriberStub.create(subscriberStubSettings)) {
      String subscriptionName = ProjectSubscriptionName.format(projectId, subscriptionId);
      PullRequest pullRequest =
          PullRequest.newBuilder()
              .setMaxMessages(numOfMessages)
              .setSubscription(subscriptionName)
              .build();

      // Use pullCallable().futureCall to asynchronously perform this operation.
      PullResponse pullResponse = subscriber.pullCallable().call(pullRequest);
      List<String> ackIds = new ArrayList<>();
      for (ReceivedMessage message : pullResponse.getReceivedMessagesList()) {
        // Handle received message
        // ...
        ackIds.add(message.getAckId());
      }
      // Acknowledge received messages.
      AcknowledgeRequest acknowledgeRequest =
          AcknowledgeRequest.newBuilder()
              .setSubscription(subscriptionName)
              .addAllAckIds(ackIds)
              .build();

      // Use acknowledgeCallable().futureCall to asynchronously perform this operation.
      subscriber.acknowledgeCallable().call(acknowledgeRequest);
      System.out.println(pullResponse.getReceivedMessagesList());
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const projectId = 'YOUR_PROJECT_ID';
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';

// Imports the Google Cloud client library. v1 is for the lower level
// proto access.
const {v1} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use.
const subClient = new v1.SubscriberClient();

async function synchronousPull() {
  const formattedSubscription = subClient.subscriptionPath(
    projectId,
    subscriptionName
  );

  // The maximum number of messages returned for this request.
  // Pub/Sub may return fewer than the number specified.
  const request = {
    subscription: formattedSubscription,
    maxMessages: 10,
  };

  // The subscriber pulls a specified number of messages.
  const [response] = await subClient.pull(request);

  // Process the messages.
  const ackIds = [];
  for (const message of response.receivedMessages) {
    console.log(`Received message: ${message.message.data}`);
    ackIds.push(message.ackId);
  }

  // Acknowledge all of the messages. You could also ackknowledge
  // these individually, but this is more efficient.
  const ackRequest = {
    subscription: formattedSubscription,
    ackIds: ackIds,
  };
  await subClient.acknowledge(ackRequest);

  console.log('Done.');
}

synchronousPull().catch(console.error);

PHP

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

use Google\Cloud\PubSub\PubSubClient;

/**
 * Pulls all Pub/Sub messages for a subscription.
 *
 * @param string $projectId  The Google project ID.
 * @param string $subscriptionName  The Pub/Sub subscription name.
 */
function pull_messages($projectId, $subscriptionName)
{
    $pubsub = new PubSubClient([
        'projectId' => $projectId,
    ]);
    $subscription = $pubsub->subscription($subscriptionName);
    foreach ($subscription->pull() as $message) {
        printf('Message: %s' . PHP_EOL, $message->data());
        // Acknowledge the Pub/Sub message has been received, so it will not be pulled multiple times.
        $subscription->acknowledge($message);
    }
}

Protocol

Request:

POST https://pubsub.googleapis.com/v1/projects/myproject/subscriptions/mysubscription:pull

{
  "returnImmediately": "false",
  "maxMessages": "1"
}

Response:

200 OK

{
  "receivedMessages": [{
    "ackId": "dQNNHlAbEGEIBERNK0EPKVgUWQYyODM2LwgRHFEZDDsLRk1SK...",
    "message": {
      "data": "SGVsbG8gQ2xvdWQgUHViL1N1YiEgSGVyZSBpcyBteSBtZXNzYWdlIQ==",
      "messageId": "19917247034"
    }
  }]
}

Request:

POST https://pubsub.googleapis.com/v1/projects/myproject/subscriptions/mysubscription:acknowledge

{
  "ackIds": [
    "dQNNHlAbEGEIBERNK0EPKVgUWQYyODM2LwgRHFEZDDsLRk1SK..."
  ]
}

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

from google.cloud import pubsub_v1

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"

subscriber = pubsub_v1.SubscriberClient()
subscription_path = subscriber.subscription_path(project_id, subscription_id)

NUM_MESSAGES = 3

# Wrap the subscriber in a 'with' block to automatically call close() to
# close the underlying gRPC channel when done.
with subscriber:
    # The subscriber pulls a specific number of messages.
    response = subscriber.pull(
        request={"subscription": subscription_path, "max_messages": NUM_MESSAGES}
    )

    ack_ids = []
    for received_message in response.received_messages:
        print(f"Received: {received_message.message.data}.")
        ack_ids.append(received_message.ack_id)

    # Acknowledges the received messages so they will not be sent again.
    subscriber.acknowledge(
        request={"subscription": subscription_path, "ack_ids": ack_ids}
    )

    print(
        f"Received and acknowledged {len(response.received_messages)} messages from {subscription_path}."
    )

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
subscription.pull.each do |message|
  puts "Message pulled: #{message.data}"
  message.acknowledge!
end

Pub/Sub delivers a list of messages. If the list has multiple messages, Pub/Sub orders the messages with the same ordering key.

Note that to achieve low message delivery latency with synchronous pull, it is important to have many simultaneously outstanding pull requests. As the throughput of the topic increases, more pull requests are necessary. In general, asynchronous pull is preferable for latency-sensitive applications.

Synchronous Pull with Lease Management

An individual message's processing may exceed the preconfigured acknowledgement deadline, also known as the lease. To avoid redelivery on these messages, the client libraries provide a way to reset their acknowledgement deadlines (except for the Go client library, which automatically modifies the acknowledgement deadlines for polled messages), as shown by the samples below:

C#

Before trying this sample, follow the C# setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub C# API reference documentation.


using Google.Cloud.PubSub.V1;
using Grpc.Core;
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;

public class PullMessageWithLeaseManagementSample
{
    public int PullMessageWithLeaseManagement(string projectId, string subscriptionId, bool acknowledge)
    {
        SubscriptionName subscriptionName = SubscriptionName.FromProjectSubscription(projectId, subscriptionId);
        SubscriberServiceApiClient subscriberClient = SubscriberServiceApiClient.Create();

        var ackIds = new List<string>();
        try
        {
            PullResponse response = subscriberClient.Pull(subscriptionName, returnImmediately: false, maxMessages: 20);

            // Print out each received message.
            foreach (ReceivedMessage msg in response.ReceivedMessages)
            {
                ackIds.Add(msg.AckId);
                string text = Encoding.UTF8.GetString(msg.Message.Data.ToArray());
                Console.WriteLine($"Message {msg.Message.MessageId}: {text}");

                // Modify the ack deadline of each received message from the default 10 seconds to 30.
                // This prevents the server from redelivering the message after the default 10 seconds
                // have passed.
                subscriberClient.ModifyAckDeadline(subscriptionName, new List<string> { msg.AckId }, 30);
            }
            // If acknowledgement required, send to server.
            if (acknowledge && ackIds.Count > 0)
            {
                subscriberClient.Acknowledge(subscriptionName, ackIds);
            }
        }
        catch (RpcException ex) when (ex.Status.StatusCode == StatusCode.Unavailable)
        {
            // UNAVAILABLE due to too many concurrent pull requests pending for the given subscription.
        }
        return ackIds.Count;
    }
}

Java

Before trying this sample, follow the Java setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Java API reference documentation.


import com.google.cloud.pubsub.v1.stub.GrpcSubscriberStub;
import com.google.cloud.pubsub.v1.stub.SubscriberStub;
import com.google.cloud.pubsub.v1.stub.SubscriberStubSettings;
import com.google.pubsub.v1.AcknowledgeRequest;
import com.google.pubsub.v1.ModifyAckDeadlineRequest;
import com.google.pubsub.v1.ProjectSubscriptionName;
import com.google.pubsub.v1.PullRequest;
import com.google.pubsub.v1.PullResponse;
import com.google.pubsub.v1.ReceivedMessage;
import java.io.IOException;
import java.util.ArrayList;
import java.util.List;

public class SubscribeSyncWithLeaseExample {
  public static void main(String... args) throws Exception {
    // TODO(developer): Replace these variables before running the sample.
    String projectId = "your-project-id";
    String subscriptionId = "your-subscription-id";
    Integer numOfMessages = 10;

    projectId = "tz-playground-bigdata";
    subscriptionId = "uno";

    subscribeSyncWithLeaseExample(projectId, subscriptionId, numOfMessages);
  }

  public static void subscribeSyncWithLeaseExample(
      String projectId, String subscriptionId, Integer numOfMessages)
      throws IOException, InterruptedException {
    SubscriberStubSettings subscriberStubSettings =
        SubscriberStubSettings.newBuilder()
            .setTransportChannelProvider(
                SubscriberStubSettings.defaultGrpcTransportProviderBuilder()
                    .setMaxInboundMessageSize(20 << 20) // 20 MB
                    .build())
            .build();

    try (SubscriberStub subscriber = GrpcSubscriberStub.create(subscriberStubSettings)) {

      String subscriptionName = ProjectSubscriptionName.format(projectId, subscriptionId);

      PullRequest pullRequest =
          PullRequest.newBuilder()
              .setMaxMessages(numOfMessages)
              .setSubscription(subscriptionName)
              .build();

      // Use pullCallable().futureCall to asynchronously perform this operation.
      PullResponse pullResponse = subscriber.pullCallable().call(pullRequest);

      List<String> ackIds = new ArrayList<>();

      for (ReceivedMessage message : pullResponse.getReceivedMessagesList()) {
        ackIds.add(message.getAckId());

        // Modify the ack deadline of each received message from the default 10 seconds to 30.
        // This prevents the server from redelivering the message after the default 10 seconds
        // have passed.
        ModifyAckDeadlineRequest modifyAckDeadlineRequest =
            ModifyAckDeadlineRequest.newBuilder()
                .setSubscription(subscriptionName)
                .addAckIds(message.getAckId())
                .setAckDeadlineSeconds(30)
                .build();

        subscriber.modifyAckDeadlineCallable().call(modifyAckDeadlineRequest);
      }

      // Acknowledge received messages.
      AcknowledgeRequest acknowledgeRequest =
          AcknowledgeRequest.newBuilder()
              .setSubscription(subscriptionName)
              .addAllAckIds(ackIds)
              .build();

      // Use acknowledgeCallable().futureCall to asynchronously perform this operation.
      subscriber.acknowledgeCallable().call(acknowledgeRequest);
      System.out.println(pullResponse.getReceivedMessagesList());
    }
  }
}

Node.js

Before trying this sample, follow the Node.js setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Node.js API reference documentation.

/**
 * TODO(developer): Uncomment these variables before running the sample.
 */
// const projectId = 'YOUR_PROJECT_ID';
// const subscriptionName = 'YOUR_SUBSCRIPTION_NAME';

// Imports the Google Cloud client library. v1 is for the lower level
// proto access.
const {v1} = require('@google-cloud/pubsub');

// Creates a client; cache this for further use.
const subClient = new v1.SubscriberClient();

async function synchronousPullWithLeaseManagement() {
  const formattedSubscription = subClient.subscriptionPath(
    projectId,
    subscriptionName
  );

  // The maximum number of messages returned for this request.
  // Pub/Sub may return fewer than the number specified.
  const maxMessages = 1;
  const newAckDeadlineSeconds = 30;
  const request = {
    subscription: formattedSubscription,
    maxMessages: maxMessages,
  };

  let isProcessed = false;

  // The worker function is meant to be non-blocking. It starts a long-
  // running process, such as writing the message to a table, which may
  // take longer than the default 10-sec acknowledge deadline.
  function worker(message) {
    console.log(`Processing "${message.message.data}"...`);

    setTimeout(() => {
      console.log(`Finished procesing "${message.message.data}".`);
      isProcessed = true;
    }, 30000);
  }

  // The subscriber pulls a specified number of messages.
  const [response] = await subClient.pull(request);

  // Obtain the first message.
  const message = response.receivedMessages[0];

  // Send the message to the worker function.
  worker(message);

  let waiting = true;
  while (waiting) {
    await new Promise(r => setTimeout(r, 10000));
    // If the message has been processed..
    if (isProcessed) {
      const ackRequest = {
        subscription: formattedSubscription,
        ackIds: [message.ackId],
      };

      //..acknowledges the message.
      await subClient.acknowledge(ackRequest);
      console.log(`Acknowledged: "${message.message.data}".`);
      // Exit after the message is acknowledged.
      waiting = false;
      console.log('Done.');
    } else {
      // If the message is not yet processed..
      const modifyAckRequest = {
        subscription: formattedSubscription,
        ackIds: [message.ackId],
        ackDeadlineSeconds: newAckDeadlineSeconds,
      };

      //..reset its ack deadline.
      await subClient.modifyAckDeadline(modifyAckRequest);

      console.log(
        `Reset ack deadline for "${message.message.data}" for ${newAckDeadlineSeconds}s.`
      );
    }
  }
}

synchronousPullWithLeaseManagement().catch(console.error);

Python

Before trying this sample, follow the Python setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Python API reference documentation.

import logging
import multiprocessing
import sys
import time

from google.cloud import pubsub_v1

multiprocessing.log_to_stderr()
logger = multiprocessing.get_logger()
logger.setLevel(logging.INFO)
processes = dict()

# TODO(developer)
# project_id = "your-project-id"
# subscription_id = "your-subscription-id"

subscriber = pubsub_v1.SubscriberClient()
subscription_path = subscriber.subscription_path(project_id, subscription_id)

response = subscriber.pull(
    request={"subscription": subscription_path, "max_messages": 3}
)

# Start a process for each message based on its size modulo 10.
for message in response.received_messages:
    process = multiprocessing.Process(
        target=time.sleep, args=(sys.getsizeof(message) % 10,)
    )
    processes[process] = (message.ack_id, message.message.data)
    process.start()

while processes:
    # Take a break every second.
    if processes:
        time.sleep(1)

    for process in list(processes):
        ack_id, msg_data = processes[process]
        # If the process is running, reset the ack deadline.
        if process.is_alive():
            subscriber.modify_ack_deadline(
                request={
                    "subscription": subscription_path,
                    "ack_ids": [ack_id],
                    # Must be between 10 and 600.
                    "ack_deadline_seconds": 15,
                }
            )
            logger.info(f"Reset ack deadline for {msg_data}.")

        # If the process is complete, acknowledge the message.
        else:
            subscriber.acknowledge(
                request={"subscription": subscription_path, "ack_ids": [ack_id]}
            )
            logger.info(f"Acknowledged {msg_data}.")
            processes.pop(process)
print(
    f"Received and acknowledged {len(response.received_messages)} messages from {subscription_path}."
)

# Close the underlying gPRC channel. Alternatively, wrap subscriber in
# a 'with' block to automatically call close() when done.
subscriber.close()

Ruby

Before trying this sample, follow the Ruby setup instructions in Quickstart: Using Client Libraries. For more information, see the Pub/Sub Ruby API reference documentation.

# subscription_name = "Your Pubsub subscription name"
require "google/cloud/pubsub"

pubsub = Google::Cloud::Pubsub.new

subscription = pubsub.subscription subscription_name
new_ack_deadline = 30
processed = false

# The subscriber pulls a specified number of messages.
received_messages = subscription.pull max: 1

# Obtain the first message.
message = received_messages.first

# Send the message to a non-blocking worker that starts a long-running process, such as writing
# the message to a table, which may take longer than the default 10-sec acknowledge deadline.
Thread.new do
  sleep 15
  processed = true
  puts "Finished processing \"#{message.data}\"."
end

loop do
  sleep 10
  if processed
    # If the message has been processed, acknowledge the message.
    message.acknowledge!
    puts "Done."
    # Exit after the message is acknowledged.
    break
  else
    # If the message has not yet been processed, reset its ack deadline.
    message.modify_ack_deadline! new_ack_deadline
    puts "Reset ack deadline for \"#{message.data}\" for #{new_ack_deadline} seconds."
  end
end

Scaling

You may need to implement a scaling mechanism for your subscriber application to keep up with message volume. How to do this depends on your environment, but it will generally be based on backlog metrics offered through the Google Cloud's operations suite monitoring service. For details on how to do this for Compute Engine, see Scaling based on Cloud Monitoring Metrics.

Go to the Pub/Sub section of the GCP Metrics List page to learn which metrics can be monitored programmatically.

Finally, as with all distributed services, expect to occasionally retry every request.

Dealing with duplicates and forcing retries

When you do not acknowledge a message before its acknowledgement deadline has expired, Pub/Sub resends the message. As a result, Pub/Sub can send duplicate messages. Use Google Cloud's operations suite to monitor acknowledge operations with the expired response code to detect this condition. To get this data, select the Acknowledge message operations metric, then group or filter it by the response_code label. Note that response_code is a system label on a metric—it is not a metric.

Use Stackdriver to to search for expired message acknowledgement deadlines

To reduce the duplication rate, extend the message deadline.

  • Client libraries handle deadline extension automatically, but you should note that there are default limits on the maximum extension deadline that can be configured.
  • If you are building your own client library, use the modifyAckDeadline method to extend the acknowledgement deadline.

Alternately, to force Pub/Sub to retry a message, set modifyAckDeadline to 0.
