Problem-solving with ML: automatic document classification

Text documents are one of the richest sources of data for businesses: whether in the shape of customer support tickets, emails, technical documents, user reviews or news articles, they all contain valuable information that can be used to automate slow manual processes, better understand users, or find valuable insights. However, traditional algorithms struggle at processing these unstructured documents, and this is where machine learning comes to the rescue!

In this blog post, we will show how off-the-shelf ML tools can be used to automatically label news articles. The approach we’ll describe can be used in any task related to processing text documents, and even to other types of ML tasks. We will also learn how data can be extracted and pre-processed, how we can make some initial observations about it, how to build ML models, and—last but not least—how to evaluate and interpret them.

We’ll use a public dataset from the BBC comprised of 2225 articles, each labeled under one of 5 categories: business, entertainment, politics, sport or tech. Our goal will be to build a system that can accurately classify previously unseen news articles into the right category.
The Python code used in this article and some accompanying text and plots are available as a Colab notebook.

Data extraction and exploration

Data is the essential resource for any ML project. Fortunately, there are plenty of datasets freely available in Google BigQuery Public Datasets.

For this blog post, we’ll use the BBC News dataset. It can either be extracted from BigQuery and exported to CSV, or directly downloaded from its original source.

Here is a sample from this dataset:

We use pandas to load this as a DataFrame, and add an integer category_id (which will be handy later on):

The DataFrame is a useful data structure, first popularized by the R language, that allows us to easily transform and navigate our dataset in an efficient manner.

Data analysis

Before diving head-first into training machine learning models, we should become familiar with the structure and characteristics of our dataset: these properties might inform our problem-solving approach.First, it’s always useful to look at the number of documents per class:

Here, we see that the number of articles per class is roughly balanced, which is helpful! If our dataset were imbalanced, we would need to carefully configure our model or artificially balance the dataset, for example by undersampling or oversampling each class.

To further analyze our dataset, we need to transform each article's text to a feature vector, a list of numerical values representing some of the text’s characteristics. This is because most ML models cannot process raw text, instead only dealing with numerical values.

One common approach for extracting features from text is to use the bag of words model: a model where for each document, an article in our case, the presence (and often the frequency) of words is taken into consideration, but the order in which they occur is ignored.

Specifically, for each term in our dataset, we will calculate a measure called Term Frequency, Inverse Document Frequency, abbreviated to tf-idf. This statistic represents words’ importance in each document. We use a word's frequency as a proxy for its importance: if "football" is mentioned 25 times in a document, it might be more important than if it was only mentioned once. We also use the document frequency (the number of documents containing a given word) as a measure of how common the word is. This minimizes the effect of stop-words such as pronouns, or domain-specific language that does not add much information (for example, a word such as "news" that might be present in most documents).

We’ll use sklearn (also known as scikit-learn), a machine learning library that is particularly accessible to beginners. Within sklearn, we’ll use the TfidfVectorizer class to calculate a tf-idf vector for each of our documents:

Note that we pass some additional parameters to the tfidf class: setting sublinear_tf means that we will use the log of the frequency, as word frequencies follow an exponential distribution (see Zipf law), we normalize our vectors to l2 norm so that the length of a document does not bias its representation, and we also consider bigrams (pairs of words) as these might carry a different meaning than each of their components separately (e.g “box office” vs “box” and “office”).

The resulting features variable contains one row of numerical features (each representing the tf-idf for a word or pair of words) for each of our documents. This representation is not only useful for solving our classification task, but also to familiarize ourselves with the dataset. For example, we can use the chi-squared test to find the terms are the most correlated with each of the categories:

We can also use dimensionality reduction techniques, such as PCA or t-SNE to project our high dimensional tf-idf features into a 2D plane, where they can be visualized. This is done by finding a projection that minimizes the information lost (PCA) or keeps nearby points in the high-dimensional space close to each other in the projected space (t-SNE). Below is the result of clustering a third of the articles in our dataset using t-SNE:

Good news: we can clearly see that different article categories fall in different areas, which means that we should expect highly accurate classification performance.One thing to note, however, is the presence of some outliers: articles from one category appearing within the bounds of a different category. Upon closer inspection, these seem to be articles that are difficult to classify even by hand, for example articles about two topics at once (e.g., an article about the football club Arsenal seeking to be listed on the London Stock Exchange).

Model training and evaluation

Metrics

First, it is vital to choose which metric to optimize for. Accuracy (the percentage of correct classifications) is the most commonly used metric, but it is not always the right choice: if we are trying to detect fraudulent monetary transactions, which might constitute less than 0.01% of the total transactions, a model that would classify all users as being non-fraudulent would have 99.99% accuracy! Because of this, we need to carefully choose our metrics.
Here, we are dealing with a multi-class classification task (assigning a label out of multiple possible values). Given the relative balance of our dataset, accuracy would be an appropriate metric. If one of the labels was more important than the others, we could look at Precision and Recall for each class, or use the ROC curve, and optimize the Area Under the Curve (ROC AUC).

Choice of model

scikit-learn provides implementations for a large number of machine learning models, spanning a few different families:

• Linear models: Linear Regression, Logistic Regression, ...
• Ensemble models: Random Forest, Gradient Boosting Trees, Adaboost, ...
• Bayesian models: (Multinomial/Gaussian/...) Naive Bayes, Gaussian Processes, ...
• Support Vector Machines, k-Nearest Neighbors, and various other models.

Ultimately, no model is universally superior to all other models, and the performance of a model greatly depends on the the data used and the nature of the classification/prediction problem solved. This is known as the No Free Lunch Theorem.

Now, let’s benchmark the following three models:

• Logistic Regression: A linear classifier, mostly similar to traditional linear regression, but that fits the output of the logistic function.
• (Multinomial) Naive Bayes: A Bayesian model that assumes total independence between features. In our case, this means that P("football") is unrelated to P("stadium"), which of course is a terrible assumption. Still, this model works surprisingly well with the Bag of Words model, and has notably been used for spam detection.
• Random Forest: Random Forest (as the name might suggest) is the ensembling of a large number of decision trees, each trained on a random subset of the input features. They work well when complex feature-relations are involved and are relatively robust to overfitting.

Model evaluation

One common mistake when evaluating a model is to train and test it on the same dataset: this is problematic because this will not evaluate how well the model works in realistic conditions, on unseen data, and models that overfit to the data will seem to perform better.
It is common practice to split the data in three parts:

• A training set that the model will be trained on.
• A validation set used for finding the optimal parameters (as discussed previously).
• A test set to evaluate the model’s performance.

We evaluate our models using this technique (with five validation folds) to obtain the following results:

The results for the Random Forest model show a large variance, the sign of a model that is overfitting to its training data. Running cross-validation is vital, because results from a single train/test split might be misleading.We also notice that both Multinomial Naive Bayes and Logistic Regression perform extremely well, with Logistic Regression having a slight advantage with a median accuracy of around 97%!With such results, we could just pack our things and consider the task complete, but it’s good to apply a healthy dose of skepticism, especially when results are this good.

Model interpretation

Given the very high accuracy of our model, almost all the predictions end up on the diagonal (predicted label = actual label), right where we want them to be!

Let’s examine the misclassified examples:

'business' predicted as 'politics' : 2 examples.

'tech' predicted as 'business' : 5 examples.

'politics' predicted as 'tech' : 2 examples.

Most of these examples are at the intersection of the ground truth category and the one predicted,  which means even humans would struggle to classify them. This sort of noise is expected, and it is often unrealistic to aim for a model that achieves 100% accuracy.

We can look deeper into how the model works by determing which terms contribute the most to a document’s classification in each of the categories:

This output seems consistent with the terms we would expect, with the exception of the terms in bold, especially in the "tech" category, that are either more reflective of the editorial style ("said mr" or "analysts said") of each category, or even explicit bigrams (such as "bbc news", "news website" or "bbc sport") that are among the most predictive for different categories.

We can confirm that although unrelated to technology, more than 81% of articles containing the bigram "news website" are ‘tech’ articles. This is called a data leakage, which occurs when information about the label we want to predict is accidentally added to the training set. In this specific case, our model still works equally well when excluding the leaky terms, but it's always good to be skeptical when a model performs much better than expected. Accordingly, a robust approach requires an interpretable model instead of black-boxes that might work very well on the test set, but fail on unseen data.

Conclusion

1. Load and pre-process data.
2. Analyze patterns in the data, to gain insights.
3. Train different models, and rigorously evaluate each of them.
4. Interpret the trained model.
