How To Submit Security Tokens to an API Provider, Pt. 2
Robert Broeckelmann is a principal consultant at Levvel. He focuses on API management, integration, and identity–especially where these three intersect. He’s worked with clients across the financial, healthcare, and retail fields. Lately, he’s been working with Apigee Edge, WebSphere DataPower, and 3Scale by Red Hat.
In a previous post, I discussed a variety of considerations regarding how bearer tokens should be passed from an API consumer to an API provider. I explored two approaches to client-side bearer token storage: cookies and HTML5 local storage. Here, I’ll look at the implications that these two approaches pose for native mobile apps, traditional web apps, and single page applications (SPAs).
Of course, there are plenty of things that don’t fall perfectly into one of these categories (for a more detailed analysis of the evolution of web applications, see this), but mobile, web, and SPAs comprise a large proportion of the use cases.
Most concerns come down to XSS vulnerabilities and cross-site request forgery (CSRF) attacks. Of course, if the device or server-side components have been compromised in some way, then this entire discussion is moot.
SPAsIf HTML5 local storage is used, then the token is passed in the authorization header. Unlike with cookies, information stored in local storage is not automatically transmitted to the server (this does place an additional burden on the developer, but can be mitigated with supporting libraries).
Attack vectors include:
- CSRF: Conventional wisdom suggests that this is not an issue because the attacking code would not have access to the JWT in the HTML5 local storage for the API endpoint. I’m not going to debate this or dissect the notion here, but let’s assume that all interaction between the SPA and its backend API use standard anti-CSRF patterns as described by OWASP. They describe two steps that should be taken: verify the same origin with standard headers (or a known origin), and require some type of randomly generated value be presented with each request that wouldn’t be known to the CSRF instigator. In a stateless REST API, both of these can be challenging. But many of the major frameworks provide support for implementing this functionality.
- CSRF: This is possible. Any request that is made (regardless of what’s triggering it) to the API from a browser session will include all cookies that are defined for the API endpoint. In this case, the mitigation strategies described above are absolutely imperative.
Let’s assume that the API the mobile application is interacting with is the same one that is utilized by a SPA application and other API consumer actors. Attack vectors include:
- CSRF: This is only possible if a library is being use that includes cookies automatically. So, it depends. However, as always, the mitigation strategies described in the previous section should be used.
Traditional web applicationsFor our purposes, the difference between the SPA above and the traditional web application hinges on whether the server returns full HTML pages or JSON objects (or maybe XML). For the most part, the information provided in the SPA section applies here with the following exceptions.
If HTTP cookies are used for storage and transportation, then the attack vectors of concern are:
- XSS: Same patterns described above should be used.
- CSRF: Synchronizer (CSRF) token patterns can be used with the stateful security model.
So which approach should be used?As I’ve mentioned in other posts, I always fall back on a standards-based approach to security. This implies that per RFC 6750, the bearer token should be placed in the HTTP request authorization header for each API call and the token stored in HTML5 local or session storage (for brower-based applications). For many IdPs, libraries will be provided that abstract these details away.
Is this the only way of accomplishing the desired effect? Obviously, no. But in my attempts to implement standards-based security solutions, it‘s the approach I recommend. Appropriate defense strategies for XSS and CSRF must be used, and, thankfully, can be largely accomplished with functionality in popular frameworks.
